Little Dot Q USB DAC and Headphone Amplifier &

Little Dot Q USB DAC and Headphone Amplifier & MINI DAC Introduction: The Little Dot Q is a hybrid vacuum tube pre-stage (6n16d), transistor output stage (BC818/BC808 and MC33078) headphone amplifier with USB DAC (Burr-Brown PCM2704)! More information available soon! Technical Specifications: Inputs: 3.5mm (1/8") mini-stereo mini-USB (for DAC) Output: 3.5mm (1/8") stereo headphone Frequency Response: 10Hz - 50KHz (-3dB) THD+N: 0.1% (1 Vrms @ 1000Hz) Signal-to-Noise: 92 dB User Selectable Gain Settings: Low (Gain of 2.5x) and High (Gain of 5x) Power Output: 300 mW @ 32 ohms 100 mW @ 300 ohmsRecommended Headphone Impedance: 32 - 300 ohms Power Consumption: 10 VA Measurements: Amplifier: 60 mm (diameter) by 50mm (height) Power Supply: 145mm (length) by 55mm (width) by 50mm (height)Weight: Amplifier: 106 grams Power Supply: 890 gramsAvailable in either 110-120VAC or 220-240VAC One Year Official Little Dot WarrantyPower Cord Note: Little Dot amplifiers ships with a standard Type-B power cord (American 3-pin or U-ground) suitable for use in areas such as North America, Japan, Taiwan, etc. If your country's outlets use other power cord types (ex. Schuko) you will need to provide you own power cord. You likely have several spares around your home, as any standard power cord (like your computer's power cord) will work perfectly fine. We do apologize for any inconvenience!
